TP821
Cree LED
4A@12V,2A@24V
48w
9-32V
Flood/Spot
IP67
2 Years
CE RoHS
Custom logo, packaging
PRODUCT INFORMATION：
Description:
Thickness of our printed circuit board is 1.6mm, heavy copper layers are used for high current or to help dissipate heat.
Our circuit is made to resist the interference from overcurrent & overvoltage attacks.Thereby improve the stability of LEDs.
Features:
1. Flood and spot light beam are provided. 3. The shape of the light is unique and more eye-catching 5. IP 67 : Completely sealed against dust and water. | 2. Aluminum body housing provides maximum protection 4. The package includes mounting bracket and wiring |
Specification
Part: TP821 Wattage: 48w (16pcs*3W Cree led) Raw Lumen: 2800 lm Current Draw: 4A@12V,2A@24V Operating Voltage:9-32V Color Temperature: 6000K Beam Pattern: Flood/Spot Lens Material: PC Housing Material: AluminiumAlloy IP Rating: IP67 Working Temperature: -45-80℃ Mounting Hardware: M10 Bracket Adjustment: 150 degree up/down. Cable Length: About 40cm (15') Lifetime: 50000 Hours | Approval: CE RoHS Warranty: 2 Years Packing: One light in one Individual box, 12PCS in one carton. G. W.:20KG; Size: 57.5*31*24.5CM
|
APPLICATIONS
